T1 3/4 Midget Flange Base LED 6 to 32 Volts product 66458
Actual Product may vary from picture shown.
One product per package unless otherwise stated.

T1 3/4 Midget Flanged Base Flat Top LED Bulb 6 to 32 Volts DC

Product Code: 66458

USD Price: 1.49
spacer   Volume Discount Percentage   spacer
 Buy 2 or more and save 2.00%
 Buy 4 or more and save 3.00%
 Buy 6 or more and save 4.00%
 Buy 8 or more and save 5.00%
 Buy 10 or more and save 6.00%
 Buy 25 or more and save 7.00%
 Buy 100 or more and save 8.00%
Qty: Add To Cart

Buy Now
Add To Saved Cart
Warranty: 12 Months

T1 3/4 Midget Flanged Base Flat Top LED Bulb 6 to 32 Volts DC. 120 degree viewing angle. Wide voltage 6 to 32 volts DC and will have the same brightness. Up to 7 Lumen output. Works negative ground DC. Long life up to 30,000 hours. Available in White 6000-6500K and Warm White 3000K. CE and Rohs. Up to 7 Lumen output. This bulb is dimmable from 2.5 to 10 Volts, from 6 to 32 Volt this bulb is not dimmable. Uses only 7ma@12 Volts. Direct replacement for: 327, 328, 330, 332, 345, 349, 350, 356, 377, 380, 381, 382, 387, 394, 8918, WL-330, 472-037, 472-054, MS25237-330, 12000-0009. LED replacement for incandescent lamps. Approximate length is .540", approximate diameter of base is .244", approximate diameter of flange is .278", approximate lens diameter is .192", approximate lens length is .160", approximate length of base is .380". Works at 2.5 Volts but very dim. Compatible with MF6
